Public Member Functions | |
| uint8_t | sendSMS (const String &phone, const String &sms) |
| uint8_t | connect (void) |
| void | disconnect (void) |
| uint8_t | getRSSI (void) |
| uint8_t | setClock (const char *time) |
| DateTime | now (void) |
| uint8_t | begin (long baud, uint8_t unlock_only=0) |
| uint8_t | changeIPR (long baud) |
| uint8_t | isRegistered (void) |
| uint8_t | isAttached (void) |
| void | softSwitch (void) |
| void | softReset (void) |
| uint8_t | init (uint8_t unlock_only=0) |
| virtual void | i_begin (long baud)=0 |
| virtual void | i_end (void)=0 |
| void | flushMTU (void) |
| void | finishTransmissionMode (void) |
 Public Member Functions inherited from BayTCPInterface | |
| uint8_t | sendPayload (void) |
| uint8_t | sendMultiFromBuffer (uint16_t maxsize=5000) |
| void | setConfig (const char *str, uint8_t index) |
| void | readConfigFromStringPGM (const char *string) |
| void | readConfigFromFile (const char *file) |
| void | readConfigFromEEPROM (int eeoffset=BayTCP_EEPROM_OFFSET) |
| void | writeConfigToEEPROM (int eeoffset=BayTCP_EEPROM_OFFSET) |
| const char * | getConfig (void) |
| const uint8_t * | parseMAC (const char *str) |
| const uint8_t * | parseIP (const char *str) |
| uint8_t | hex2int (const char c) |
| char ** | getConfigPointer (uint8_t index) |
| Public Member Functions inherited from BayEOS | |
| BayEOS (void) | |
| virtual uint8_t | readIntoPayload (int timeout=5000) |
| virtual int | available (void) |
| uint8_t | sendError (const String &s) |
| uint8_t | sendMessage (const String &s) |
| void | startFrame (uint8_t type) |
| void | startOriginFrame (const String &o, uint8_t routed=0) |
| void | startDataFrame (uint8_t subtype=BayEOS_Float32le, uint8_t checksum=0) |
| void | startDataFrameWithOrigin (uint8_t subtype, const String &o, uint8_t checksum=0, uint8_t routed=0) |
| uint8_t | addChannelValue (float v, uint8_t channel_number=0) |
| uint8_t | addChannelValue (double v, uint8_t channel_number=0) |
| uint8_t | addChannelValue (long v, uint8_t channel_number=0) |
| uint8_t | addChannelValue (unsigned long v, uint8_t channel_number=0) |
| uint8_t | addChannelValue (int v, uint8_t channel_number=0) |
| uint8_t | addChannelValue (unsigned int v, uint8_t channel_number=0) |
| uint8_t | addChannelValue (int8_t v, uint8_t channel_number=0) |
| uint8_t | addChannelValue (uint8_t v, uint8_t channel_number=0) |
| uint8_t | addChannelValue (float v, const char *channel_label) |
| uint8_t | addChannelValue (double v, const char *channel_label) |
| uint8_t | addChannelValue (long v, const char *channel_label) |
| uint8_t | addChannelValue (unsigned long v, const char *channel_label) |
| uint8_t | addChannelValue (int v, const char *channel_label) |
| uint8_t | addChannelValue (unsigned int v, const char *channel_label) |
| uint8_t | addChannelValue (int8_t v, const char *channel_label) |
| uint8_t | addChannelValue (uint8_t v, const char *channel_label) |
| uint8_t | addChecksum (void) |
| uint8_t | validateChecksum (void) |
| void | startRoutedFrame (uint16_t sourceMyID, uint16_t sourcePANID, uint8_t rssi=0) |
| void | startDelayedFrame (unsigned long delay) |
| void | startTimestampFrame (unsigned long timestamp) |
| void | startCommand (uint8_t cmd_api) |
| void | startCommandResponse (uint8_t cmd_api) |
| uint8_t | addToPayload (uint8_t b) |
| uint8_t | addToPayload (const void *p, uint8_t length) |
| uint8_t | addToPayload (const uint8_t *c) |
| uint8_t | addToPayload (const String &s) |
| uint8_t | addToPayload (float f) |
| uint8_t | addToPayload (unsigned long l) |
| uint8_t | addToPayload (long l) |
| uint8_t | addToPayload (int w) |
| uint8_t | addToPayload (uint16_t w) |
| uint8_t | getPayloadBytesLeft (void) const |
| uint8_t | getPayloadLength (void) const |
| uint8_t | getPacketLength (void) const |
| const uint8_t * | getPayload (void) const |
| uint8_t | getPayload (uint8_t index) const |
| uint8_t | sendOrBuffer (void) |
| uint8_t | sendFromBuffer (void) |
| uint8_t | writeToBuffer (void) |
| uint8_t | readFromBuffer (void) |
| uint8_t | readBinaryFromBuffer (unsigned long pos) |
| uint8_t | readBinaryFromBuffer (unsigned long pos, unsigned long end, unsigned long vpos) |
| void | setBuffer (BayEOSBuffer &buffer, uint16_t max_skip=0) |
Public Attributes | |
| long | _baud |
| uint8_t | _powerPin |
| uint8_t | _resetPin |
| Public Attributes inherited from BayTCPInterface | |
| boolean | _urlencode |
| Public Attributes inherited from BayEOS | |
| uint8_t | _payload [BayEOS_MAX_PAYLOAD] |
| uint8_t | _next |
| uint8_t | _success |
| uint8_t | _failure_counter |
| uint16_t | _max_skip |
| uint16_t | _skip_counter |
| BayEOSBuffer * | _buffer |
Additional Inherited Members | |
| Protected Member Functions inherited from BayTCPInterface | |
| virtual int | i_available ()=0 |
| void | printPostHeader (uint16_t size) |
| void | setConfigPointers (void) |
| uint8_t | addToConfigBuffer (uint8_t offset, const char *str) |
| void | skipChars (void) |
| uint8_t | wait_forOK (uint16_t timeout) |
| uint8_t | wait_forPGM (const char *str, uint16_t timeout, uint8_t bytes=0, char *buffer=NULL) |
| uint8_t | wait_for_available (uint16_t *timeout, int bytes=1) |
| void | printPGM (const char *str) |
| void | printlnPGM (const char *str) |
| void | serialprintPGM (const char *str) |
| void | serialprintlnPGM (const char *str) |
| int | strlenURLencoded (const char *str) |
| void | printURLencoded (const char *str) |
| Protected Attributes inherited from BayTCPInterface | |
| uint8_t | _mac_ip [6] |
| char | _config_buffer [BayTCP_CONFIG_SIZE] |
| char | _pgm_buffer [20] |
| char * | _server |
| char * | _port |
| char * | _path |
| char * | _user |
| char * | _password |
| char * | _sender |
| char * | _apn |
| char * | _prov_pw |
| char * | _prov_user |
| char * | _pin |
| char | _base64buffer [BayTCP_BUFFER] |
| uint8_t | _tx_error_count |
| uint16_t | _mtu |
| Static Protected Attributes inherited from BayTCPInterface | |
| static const char *const | _urlencodedChars ="$&+,/:;=?@ <>#%{}|~[]`" |
Detailed Description
Definition at line 24 of file BayTCPSim900.h.
Member Function Documentation
◆ begin()
| uint8_t BayGPRSInterface::begin | ( | long | baud, |
| uint8_t | unlock_only = 0 |
||
| ) |
Switch on GPRS-Modem 0 == GPRS-modem is up and responding OK 1 == Communication-ERROR 2 == PIN failed 3 == PIN locked 4 == Not CREG 5 == Not CGATT 6 == No SIM Card
if unlock_only is set, function returns already after unlocking the modem
Definition at line 315 of file BayTCPSim900.cpp.
◆ connect()
|
virtual |
Connect to the web through apn 0 == OK 1 == Network TIMEOUT 2 == NO Communication 3 == PIN failed 4 == PIN locked 5 == Not CREG 6 == Not CGATT 7 == No SIM Card Omit, if you just want to send SMS
Implements BayTCPInterface.
Definition at line 235 of file BayTCPSim900.cpp.
◆ disconnect()
|
virtual |
Disconnect from the web
Implements BayTCPInterface.
Definition at line 292 of file BayTCPSim900.cpp.
◆ getRSSI()
| uint8_t BayGPRSInterface::getRSSI | ( | void | ) |
Disconnect from the web
Definition at line 161 of file BayTCPSim900.cpp.
◆ init()
| uint8_t BayGPRSInterface::init | ( | uint8_t | unlock_only = 0 | ) |
Switch on GPRS-Modem 0 == OK 1 == NO Communication 2 == PIN failed 3 == PIN locked 4 == Not CREG 5 == Not CGATT 6 == No SIM Card
Definition at line 39 of file BayTCPSim900.cpp.
◆ isAttached()
| uint8_t BayGPRSInterface::isAttached | ( | void | ) |
Checks if modem is attached to network
Definition at line 178 of file BayTCPSim900.cpp.
◆ isRegistered()
| uint8_t BayGPRSInterface::isRegistered | ( | void | ) |
Checks if modem is registered to network
Definition at line 169 of file BayTCPSim900.cpp.
◆ now()
| DateTime BayGPRSInterface::now | ( | void | ) |
Get time from RTC
Definition at line 186 of file BayTCPSim900.cpp.
◆ sendSMS()
| uint8_t BayGPRSInterface::sendSMS | ( | const String & | phone, |
| const String & | sms | ||
| ) |
Send SMS Use international phone numbers +49151xxxxx
Definition at line 301 of file BayTCPSim900.cpp.
◆ setClock()
| uint8_t BayGPRSInterface::setClock | ( | const char * | time | ) |
Set RTC time has to be in the format "YY/MM/DD,HH:MM:SS-01"
Definition at line 146 of file BayTCPSim900.cpp.
◆ softReset()
| void BayGPRSInterface::softReset | ( | void | ) |
perform software reset operation only works if a resetPin is set
Definition at line 130 of file BayTCPSim900.cpp.
◆ softSwitch()
| void BayGPRSInterface::softSwitch | ( | void | ) |
/** perform soft switch operation will switch on/off modem
Definition at line 116 of file BayTCPSim900.cpp.
The documentation for this class was generated from the following files:
- libraries/BayTCPSim900/BayTCPSim900.h
- libraries/BayTCPSim900/BayTCPSim900.cpp
